Description
- Horizontal level measuring range: 0 to 360° (4*90°)
- Audible tone at horizontal & vertical
- Set Zone function for checking relative angles.
- Low battery indication
- Flip Display: The display rotates automatically with overhead measurements.
- “Traffic Light” LED technology for the brightest display
- Thermoplastic rubber (TPR) on each end cap for better protecting from accident of drop.
- Hold function to freeze the measurement.
- Strong aluminum frame, thickness: 1.5mm on the bottom 1.2mm on the top 1.4mm on the front & back faces
- IP54 waterproof & dustproof industrial standard.
| TECHNICAL SPECIFICATIONS | ||||
|---|---|---|---|---|
| PRODUCT FEATURES | SIZE | |||
| 30cm | 60cm | 80cm | 100cm | |
| LCD MEASUREMENT ACCURACY | ± 0.1 ° | |||
| ACCURACY at 0 ° – 90 ° | ± 0.2 ° | |||
| MEASUREMENT UNITS | DEGREE/%/mm per m /IN/FT | |||
| AUTOMATIC BACKLIGHT | YES | |||
| AUTOMATIC SHUTDOWN | 180s | |||
| BATTER | 1.5V 2*AAA | |||
| 1 YEAR WARRANTY | YES | |||
| OPERATING TEMPERATURE | 0C TO 40C | |||
| MAGNETIC BASE | YES | |||
| HANGING HOLE | YES | |||
